LDV's New G10 Van

• ​Power
• Hard Working
• Comfort
• Safety
• Specifications

<

>

The G10 Van has the Power to Perform.

The G10's new generation powerful 2 litre twin cam turbo engine with Gasoline Direct Injection and Double Variable Valve Timing produces an impressive output of up to 165kW of power and 345Nm of torque. This power and torque range ensures the G10 makes light work of moving heavy loads.

The G10's engine is matched to a 6 speed ZF automatic transmission, delivering a responsive, smooth and quiet ride even under load. The gearbox also has a manual override, useful for steep descents or challenging conditions.

Rear wheel drive combined with effortless power and torque, smooth auto gear changes and a positive steering response make the G10 a delight to drive, either around town or on the highway.

The G10 Van is made for Hard Work.

The G10 Van really does make hard work a whole lot easier.

Its 5.2m3 cargo area has a payload of 1093kg and can accommodate up to two standard pallets.

Access is easy with 2 sliding doors as standard plus a rear lift tailgate which also provides protection from the weather when loading.

There are lots of options for securing cargo. The G10 has strong load tie down points both on the floor and on the wheel arches.

There is a thick, tough floor covering throughout the vehicle and an interior lining that goes half way up the side walls to protect both the vehicle and your cargo.

And to make sure you are never left in the dark, there are four lights in the load area along with an integrated step on both sides. Too easy!

The G10 Van is a Comfortable Workplace

LDV has always taken driver comfort very seriously because a comfortable driver is a safer driver. The G10 Van is a great example of this.

The spacious cabin has been designed with comfort in mind.

The driver's seat is well padded with an arm rest and a range of adjustments ensuring comfortable driver positioning.

The steering wheel is tilt adjustable and there's a well-placed step and grab handle to make getting in and out of the van easier.

The G10 comes standard with features like a quality audio system that includes a radio, MP3 connectivity, a DVD with a 7" dash LCD and Bluetooth.

Cruise control is standard, so is the rear camera and park assist.

And of course, the G10 comes with air conditioning, power front windows, power side mirrors and keyless entry.

There's even loads of storage space for your mobile office gear which turns the van into a mobile office.

Yes, everything in the G10 is designed to make your working day a lot easier.

The G10 Van is Serious about Safety.

Safety is a priority in the G10 Van whether it's the robust Lotus calibrated chassis, the ESP safety system by Bosch or the many other active and passive safety features. These include Anti-skid brakes (ABS), Electronic brake force distribution (EBD) and Emergency brake assist (EBA) all coming together to ensure braking is optimal for any driving situation.

On top of that, the G10 Van has Electronic stability control (ESC) with Roll movement intervention (RMI).

The G10 Van also comes with both driver and passenger airbags, rear fog lamps and a tyre pressure monitoring system.

When you consider that pedestrian safety hasn't been forgotten either, with the G10 offering both a rear camera with park assist and parking sensors, it's clear the G10 Van takes safety seriously.

Specifications:

---

Engine
Maximum Power (kW)
Maximum Torque (Nm)
Displacement (cc)
Transmission
Fuel Tank (Litres)
Fuel Consumption (combined L/100km)

2.0 TGI turbo charged petrol
165
330
1995
ZF Six speed automatic transmission
75
11.7

---

  Steering & Handling
Hydraulic power assisted steering
Front Suspension – Macpherson struts
Rear Suspension – Five Link Coil Springs
16" alloy wheels (6.5J x 16) Tyres 215/70R16
Full size steel spare wheel
Brakes
Front ventilated discs
Rear discs
Anti skid brakes (ABS)
Electronic brake force distribution (EBD)
Electronic stability control (ESC)
Emergency brake assist (EBA)

---

  Interior Features
2 Seats
Cruise control
Air conditioning
Power windows (front)
2 speaker radio, MP3 and DVD with a 7" in dash LCD Bluetooth phone and audio
Tilt adjustable steering wheel

                   Exterior Features
Dual side sliding doors
Lift tail gate
Power side mirrors with integrated turning signal

                                 Safety Features
Anti skid brakes (ABS)
Electronic brake force distribution (EBD)
Electronic stability control (ESC)
Emergency Brake Assist (EBA)
Roll Movement Intervention (RMI)
Driver's and passenger airbags
Rear camera with Park Assist Parking sensors with alarm
Remote keyless entry and central locking
Fog lamps rear
Tyre pressure monitoring system

                                        Dimensions
5168 Length (mm)
1980 Width (mm)
1928 Height (mm)
134 Ground clearance (mm)
3198 Wheel base (mm)
11.8 Turning circle diameter (m)
2365 Cargo area length (mm)
1590 Cargo area width at widest point (mm)
1270 Cargo area height (mm)
1278 Wheel arch width (mm)
1370 Rear door opening at widest point (mm)
1179 Rear door opening height (mm)
820 Side door opening width (mm)
1165 Side door opening height (mm)
3000 Gross vehicle mass (kg)
1907 Tare weight (kg)
1093 Payload (kg)#
1370 Front axle capacity (kg)
1630 Rear axle capacity (kg)
750 Unbraked towing capacity (kg)
1500 Braked towing capacity (kg)
5.2 Cargo Volume (m3)
3 year/100,000km (whichever occurs first) Warranty & Roadside Assist
